A: Infrared Absorption 197K.

B: The retention times of the three main isomeric peaks in the chromatogram of the Assay preparation correspond to those in the chromatogram of the Standard preparation, as obtained in the Assay.

Buffer solution, Solution A, Solution B, and Mobile phase— Prepare as directed in the Assay.

Standard solution— Prepare a solution of methyl benzenesulfonate in acetonitrile having a known concentration of about 0.2 mg per mL. Quantitatively dilute a portion of this solution with Solution A to obtain a solution having a known concentration of about 1 µg per mL.

Test solution— Transfer about 100 mg of Atracurium Besylate, accurately weighed, to a 10-mL volumetric flask, dissolve in and dilute with Solution A to volume, and mix.

Resolution solution— Transfer 1 mL of the Test solution and 5 mL of a solution containing 0.2 mg of methyl benzenesulfonate per mL to a 100-mL volumetric flask, dilute with Solution A to volume, and mix.

Chromatographic system (see Chromatography 621)— The liquid chromatograph is equipped with a 217-nm detector and a 4.6-mm × 25-cm column that contains base-deactivated packing L1. The flow rate is about 1 mL per minute. The chromatograph is programmed as follows. Chromatograph the Resolution solution, and record the peak responses as directed for Procedure: the resolution, R, between the trans-trans isomer and methyl benzenesulfonate is not less than 12.0. Chromatograph duplicate injections of the Standard solution, and record the peak responses as directed for Procedure: the responses for duplicate injections do not differ from each other by more than 12%.

Procedure— Separately inject equal volumes (about 100 µL) of the Standard solution and the Test solution into the chromatograph, record the chromatograms, and measure the responses for the methyl benzenesulfonate peaks: the peak response obtained from the Test solution is not greater than that obtained from the Standard solution. Not more than 0.01% of methyl benzenesulfonate is found.

Test Solution— Prepare as directed for Method I under Organic Volatile Impurities 467.

Standard solution— Prepare a solution containing 100 µg of toluene per mL.

Chromatographic System— Proceed as directed for Method I under Organic Volatile Impurities 467, except to use the Standard solution.

Procedure— Separately inject equal volumes (about 1 µL) of the Standard solution and the Test Solution into the chromatograph, record the chromatograms, and measure the responses for the major peaks: the toluene peak from the Test Solution is not greater than the toluene peak obtained from the Standard solution. Not more than 0.5% of toluene is found.

Buffer solution, Solution A, Solution B, and Mobile phase— Proceed as directed in the Assay.

Standard solution— Transfer 1.0 mL of the Standard preparation, prepared as directed in the Assay, to a 100-mL volumetric flask, dilute with Solution A to volume, and mix.

Test solution— Use the Assay preparation.

Chromatographic system (see Chromatography 621)— Prepare as directed in the Assay. Chromatograph the Standard solution, and record the peak responses as directed for Procedure: the responses of the cis-cis isomers from not fewer than two injections do not differ by more than 10%.

Procedure— Separately inject equal volumes (about 20 µL) of the Standard solution and the Test solution into the chromatograph, record the chromatograms, and measure all of the peak responses, except the three main isomeric peaks. Calculate the percentage of each impurity in the portion of Atracurium Besylate taken by the formula: in which C is the concentration, in mg per mL, of the cis-cis isomer in the Standard solution; W is the weight, in mg, of Atracurium Besylate taken to prepare the Test solution; ri is the peak response for each impurity obtained from the Test solution; and rS is the peak response for the cis-cis isomer obtained from the Standard solution: not more than 1.5% of any individual impurity is found, and not more than 3.5% of total impurities is found.

(Official January 1, 2007)

Buffer solution— Transfer about 10.2 g of monobasic potassium phosphate to a 1000-mL volumetric flask, and dissolve in about 950 mL of water. While stirring, adjust with phosphoric acid to a pH of 3.1, dilute with water to volume, and mix.

Solution A— Prepare a mixture of Buffer solution, acetonitrile, and methanol (75:20:5).

Solution B— Prepare a mixture of Buffer solution, methanol, and acetonitrile (50:30:20).

Mobile phase— Use variable mixtures of Solution A and Solution B as directed for Chromatographic system. Make adjustments if necessary (see System Suitability under Chromatography 621).

Standard preparation— Dissolve an accurately weighed quantity of USP Atracurium Besylate RS in Solution A to obtain a solution having a known concentration of about 1.0 mg per mL.

Assay preparation— Transfer about 100 mg of Atracurium Besylate, accurately weighed, to a 100-mL volumetric flask, dissolve in and dilute with Solution A to volume, and mix.

Chromatographic system (see Chromatography 621)— The liquid chromatograph is equipped with a 280-nm detector and a 4.6-mm × 25-cm column that contains base-deactivated packing L1. The flow rate is about 1 mL per minute. The chromatograph is programmed as follows. Chromatograph the Standard preparation, and record the peak responses as directed for Procedure: the relative retention times are about 0.8, 0.9, and 1.0 for the trans-trans isomer, the cis-trans isomer, and the cis-cis isomer, respectively; the resolution, R, between the trans-trans isomer and the cis-trans isomer and between the cis-trans isomer and the cis-cis isomer is not less than 1.1; and the relative standard deviation for replicate injections is not more than 2.0%.

Procedure— Separately inject equal volumes (about 20 µL) of the Standard preparation and the Assay preparation into the chromatograph, record the chromatograms, and measure the responses for the three isomeric peaks. Calculate the quantity, in mg, of C65H82N2O18S2 in the portion of Atracurium Besylate taken by the formula: in which C is the concentration, in mg per mL, of USP Atracurium Besylate RS in the Standard preparation; and rU and rs are the sums of the peak responses for the trans-trans isomer, the trans-cis isomer, and the cis-cis isomer obtained from the Assay preparation and the Standard preparation, respectively.
